Description

The OHAUS next generation Defender 5000 Series multifunctional bench scale is ideal for a multitude of applications, including production, packaging, inventory and shipping. Built durably and equipped with advanced features such as maximum configurability print output, GMP/GLP data output, library/user management and multiple connectivity options – the Defender 5000 is designed to simplify demanding industrial and commercial applications.

User-friendly model with an easy-to-use keypad, large backlit display and plain text on-screen prompts which guide you through operation.

Durable construction with a stainless steel platform, sand gray powder-coated steel frame & aluminum load cell. Defender meets NTEP/Measurement Canada or OIML/EC type approvals (depending on region).

Features common industrial modes and supports a 50,000-item library with 1,000 user profiles for easy data management. Includes GMP/GLP with time/date for result traceability.

Applications

Weighing, Parts Counting, Percent Weighing, Check Weighing, Dynamic Weighing (Display Hold)

Features

Display – Backlit Liquid Crystal Display (LCD), 256 x 80 pixels
Power – AC Power (Included);Rechargeable Battery (Not Included). 20 Hours with Rechargeable Battery
Communication – 2nd RS232/RS485/USB (Available as an Accessory);Ethernet (Available as an Accessory);RS232 (Included);USB Host (Available as an Accessory);WiFi/Bluetooth (Available as an Accessory)
Design – User-configurable resolution up to dual range 15,000d/3,000e (25000d/5000d for NTEP), 150% overload capacity protection, checkweighing symbols with selectable operation and audible signal settings, menu lock switch, multiple selectable operating languages, selectable environmental and auto-print settings, stability indicator, overload/underload indicators, selectable adjust contrast settings, auto-dim display, auto-off, brightness adjustment, screensaver, auto tare

Available Models

Model	Capacity	Readability	Platform Size
D52P6RQDR1	3/6kg	0.2/0.5g	305 x 305mm
D52P15RQDR1	6/15kg	0.5/1g	305 x 305mm
D52P15RQDL2	6/15kg	0.5/1g	400 x 400mm
D52P30RQDL2	15/30kg	1/2g	400 x 400mm
D52P60RQDL2	30/60kg	2/5g	400 x 400mm
D52P60RQDX2	30/60kg	2/5g	500 x 500mm
D52P60RQDV3	30/60kg	2/5g	610 x 610mm
D52P150RQDV3	60/150kg	5/10g	610 x 610mm
D52P300RQDV3	150/300kg	10/20g	610 x 610mm
D52P150RTDV3	60/150kg	5/10g	800 x 600mm
D52P300RTDV3	150/300kg	10/20g	800 x 600mm
D52P600RTDV3	300/600kg	20/50g	800 x 600mm
D52P6RQDR1-M	3/6kg	1/2g	305 x 305mm
D52P15RQDR1-M	6/15kg	2/5g	305 x 305mm
D52P15RQDL2-M	6/15kg	2/5g	400 x 400mm
D52P30RQDL2-M	15/30kg	5/10g	400 x 400mm
D52P60RQDL2-M	30/60kg	10/20g	400 x 400mm
D52P60RQDX2-M	30/60kg	10/20g	500 x 500mm
D52P60RQDV3-M	30/60kg	10/20g	610 x 610mm
D52P150RQDV3-M	60/150kg	20/50g	610 x 610mm
D52P300RQDV3-M	150/300kg	50/100g	610 x 610mm
D52P150RTDV3-M	60/150kg	20/50g	800 x 600mm
D52P300RTDV3-M	150/300kg	50/100g	800 x 600mm
D52P600RTDV3-M	300/600kg	100/200g	800 x 600mm
